ee below for the specification of the Merida eONE SIXTY, contact us if you would like an alteration to a specification and for availability:
SPECIFICATIONFRAME
·
Carbon III - carbon main frame
and rear triangle internal battery. Internal cable routing via Smart entry
ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 29" x
2.6"
MOTOR
·
Shimano Steps EP801; 85Nm
BATTERY
·
Simplo Trend Power internal
battery; 600Wh
BATTERY CAPACITY
·
600Wh
EBIKE DISPLAY
·
Shimano SC-EM800
CHARGER
·
Trendpower Simplo EU Charger; 4A
POWER BUTTON
·
Shimano satellite system on/off;
EWSW310
MODE SWITCH
·
Shimano SW-EM800-L
SHOCK
·
FOX Factory Float X2; 2 Pos
Lever
FORK
·
FOX 38 Factory eMTB+; Air; 170mm
travel; Tapered; 44mm fork offset; Max. tyre size 29" x 2.6"
GEARS
·
12
SHIFTERS
·
Limotech RM10 dropper post lever
and SRAM AXS Pod Controller
REAR DERAILLEUR
·
SRAM XX Eagle Transmission AXS
wireless
BOTTOM BRACKET
·
Part of Shimano Steps motor
CHAIN
·
SRAM XX Eagle Transmission;
Flattop
CHAINSET
·
SRAM XX Eagle Transmission E-MTB
for Steps; 34 tooth chainset with Shimano FC-EM900 165mm length crank all
sizes; hollow with MRP 1x chainguide
CASSETTE
·
SRAM XX Eagle Transmission ;
10-52; 12 speed
BRAKE LEVER
·
SRAM Code Ultimate Stealth
FRONT BRAKE
·
SRAM Code Ultimate Stealth 4
piston hydraulic disc brake caliper with SRAM HS2 220mm rotor
REAR BRAKE
·
SRAM Code Ultimate Stealth 4
piston hydraulic disc brake caliper with SRAM HS2 220mm rotor
GRIP
·
Merida Expert EC
HANDLEBAR
·
Merida Expert eTR; 780mm wide;
20mm rise
STEM
·
Merida Expert eTR II; aluminium;
35mm diameter; 0 degree rise - Stem length: 40mm (all sizes). GoPro &
Supernova mount point.
HEAD SET
·
Acros ICR Merida integrated neck
w/ Blocklock
PEDAL
·
VP Components - VPE-527
SADDLE
·
Proxim W400 T2.0 with V-mount
adapter; including Merida minitool
SEAT POST
·
Merida Team TR II; 34.9mm
diameter; in-line; all sizes 30-230mm seat post travel
WHEEL SIZE
·
29" / 27.5"
RIMS
·
Part of wheelset - DT Swiss
Spline HXC1501 spline 30 boost; carbon; Tubeless ready (tubeless tape and
valves included)
SPOKES
·
Part of wheelset
FRONT HUB
·
Part of wheelset - DT Swiss
Spline HXC1501 spline 30 boost; 110 x 15mm; 6-Bolt
REAR HUB
·
Part of wheelset - DT Swiss
Spline HXC1501 spline 30 boost; 148 x 12mm; SRAM XD; 6-Bolt with Merida Expert
TR axle including removable 6/4mm allen key
FRONT TYRE
·
Maxxis Assegai; 29" x
2.5"; Kevlar bead; folding; TR EXO+ 3C MaxxGrip
REAR TYRE
·
Maxxis DHR II; 27.5" x
2.6"; Kevlar bead, folding; 3C EXO+ TR
COLOUR
·
White/Bronze
SEASON
·
2024
FRONT LIGHT
·
Lezyne Power STVZO E115, reverse
Merida Custom Mount
REAR LIGHT
·
Lezyne LED FEMTO USB REAR STVZO
OTHER
·
Merida Team bottle cage, On-bike
charging cable and rear fender
